July 19, 2011

Technic girl from year 2000...

Surfing in a Japanese lego technic web from the early year 2000 i found this images:






















Yes a WOMAN TECHNIC FIGURE!! this shock me all day..


KIBUN website


The full site features lots of amazing mocs, furthermore thinking it where from several years ago...













rover1

rover1, a photo by roguebantha_1138 on Flickr.



helipak

helipak a video by vmln8r on Flickr.

Very nice creation for the May edition of the Technic Challenge.

Lightweight single-seat helicopter. It features a single motor, which drives a pair of contra-rotating, coaxial propellers.


July 17, 2011

Which is the real one??


I found this some days ago in Brixe63's photostream at Flickr and until I saw the following image I don't realized that all parts where built in lego pieces!! ALL PARTS!








July 15, 2011

LEGO GBC 10 modules by laurens gauwloos



In their site  laurens gauwloos pubkished this 10 modules GBC with some interesting features, and reinterpretations of known gbc concepts and techniques.



"This Lego great ball contraption "GBC" has 10 different modules and are sturing with 8 PF-M motors and 2 PF-L motors. It took me 1 month to finish it. It is 2 metre long and 30-40 centimetre width. It contains: A ball shooter, a moving bridge, 2 ball lifts, a ball accelerator, a ball wheel,.... It is powerd by 2 PF-battery boxes and 2 switches to have the righe direction. there are also many delays with gears and worm gears.
You'll see that I have used tracks for the lifts and for the ball wheel and a big shock absorber for shooting the balls."

Follow all the laurens gauwloos projects in  www.legotechnics.webs.com

July 14, 2011

Automatic gearboxes

There are a few kinds of Lego Technic automatic gearboxes, here some examples:

The first one, a two speed gearbox by Sariel, based on a 3 speed design by Misha van Beek








Another automatic design by Misha van Beek


Click Here to see it working

This gearbox by Zblj using 2 differentials switches between 1:1 and 1:5 gear ratios:



Sariel make a more compact version of this and published this two shots at facebook



From the same builder is this 3-speed "simple, yet effective gearbox, using a very unique design to change gears"





YotamPoleg show us in the first part of this video a real CVT gearbox:



Another interesting concept, this one is controlled by a centrifugal device:


By error4385

And finally my own first prototype of automatic gearbox, mixing Misha and Zblj concepts, two differentials to switch between 1:1 and 1:5 gear ratios, and a third differential to unlock the 1:5 gears when more torque is need and lock it when less torque and more speed is wanted, also the 1:1 gears got anti-return device in order to prevent the stop of the entire gearbox.

July 13, 2011

July 8, 2011

Pancake Bot

Tasty creation! Really interesting device!!

The Pancake Bot (PB) is basically a 3 axis CNC made that uses the Z coordinate as the Pancake Batter Dispenser Control. This one just happens to be made out of LEGO.



The complete entry and explanations at makermig.blogspot

July 3, 2011

Mechanical GBC train module

Yes, I say MECHANICAL instead of electronic, because this module is all made without mindstorms, wedoo or other electronic devices... mechanical automatism brought to perfection

Just see how great this is:



The loading module


And a closer image of the automatic loading mechanism:



The switch-clutch selector, equivalent to the vintage monorail LEGO system,  see the output gear and the clutch selector in booth sides:


The loading trains:


Hope this great builder make another creations and videos soon. Meanwhile check the akiyuky's previous entries in this blog or also his blog, (google translate will help a little) to check another ball factory:



July 2, 2011

Lego Technic Pneumatic Vehicle by Nico71

As a fan of steam and Lego Technic pneumatic creations this car must appear here:


It has all steam basics, boiler, flyweel, distribution valve and a "decorative" centrifugal speed regulator valve...

...Steering and pilot operated clutch!


Like almost always I recommend to watch the video to see the Moc in action!



Nico's topic on SETECHNIC  and other entries of this blog about NICO71's creations
